Shurflo 12V 4009 Water Pump Without Fittings (C-Tick Approved

A fresh water pump designed with a one-piece diaphragm and internal by-pass ensuring a long life and max performance.

Constructed for high flow demand, this updated Shurflo pump is has low noise emissions and no rapid cycling.

Features and Benefits:

• Four Independent Pump Chambers - Quiet and smooth operation
• Adjustable Pressure Shut Off - Fine tuning for customer specific application
• Self priming up to 1.8 meters (6 feet) vertical
• O-ring Check Valve Design - Long life and consistent performance
• Adjustable Bypass - Eliminates need for accumulator tank
• Run Dry Capability - Long life consistent performance
• CE & C-Tick compliant
• Must be installed with a filter.(see SKU 800-00300 or 800-00312)

Specifications:

Pump

10lts per minute

Type: 4 Chamber Diaphragm Pump

Ports: ½” - 14 NPSM-Male

Inlet PSI: 30Psi (2.1Bar) Max

Electrical

Motor: 12V DC Permanent Magnet, Intermittent Duty

Protection: Thermal Overload, Automatic Restart

Fuse: 7Amp Recommended

Materials:

Housing: Polypropylene

Hardware: Stainless and Zinc Plated Steel

Net Weight: 2.3Kg

Dimensions: 205L x 125W x 111H (mm)
